Multimatic® 255 Multiprocess Welder w/ EZ-Latch™ Dual Cylinder Running Gear & TIG Kit
Built for professionals in the MRO and light manufacturing/fabrication segments who want a smaller, versatile multiprocess welder with intuitive setup to increase efficiencies and productivity.
Description
WHAT’S INCLUDED
- Power source with 10 ft. (3 m) industrial power cord
- 15 ft. (4.5 m) 250-amp MDX™-250 MIG gun w/Bernard® AccuLock™ S consumables for .035/.045 in. (0.9/1.2 mm) wire
- 10 ft. (3 m) cable w/electrode holder & 50 mm Dinse-style connector
- 10 ft. (3 m) work cable w/clamp & 50 mm Dinse-style connector
- Flow gauge regulator and gas hose for argon or AR/CO2 mix
- .035/.045 in. (0.9/1.2 mm) reversible drive rolls
- Extra contact tips
- Material thickness gauge
- EZ-Latch™ dual cylinder running gear with elevated gun and cable rack
- Multimatic 255 TIG kit
- Two chains to secure gas cylinders
GENERAL SPECIFICATIONS
| Title | Multimatic® 255 Multiprocess Welder w/ EZ-Latch™ Dual Cylinder Running Gear & TIG Kit – 208-575V |
|---|---|
| Weldable Metals | Steel Stainless Steel Aluminum |
| Input Voltage | 208 V 220/230/240 V 460/480 V 575 V |
| Input Phase | 1-Phase |
| Input Hz | 50 / 60 Hz |
| Input Amperage | 34.7 |
| Current Type | DC |
| Max Open Circuit Voltage | 81 VDC |
| Wire Feed Speed | 50 IPM – 800 IPM |
| Portability | Handle(s) Running Gear / Cart (Standard) |
| Weld Output | CC / CV |
